ACCESS POINTS

Advantages

Dual concurrent Wi-Fi with an aggregated datarate of up to 3.550 Mbps
The LANCOM LX-6402 offers the Wi-Fi 6 standard (IEEE 802.11ax) for high-speed wireless LAN for clients in the 2.4- and 5-GHz bands. Wi-Fi 6 technology achieves transmission rates of up to 2.400 Mbps at 5 GHz and simultaneously up to 1.150 Mbps at 2.4 GHz.

4x4 Multi-User MIMO for downlinks and uplinks
Multi-user MIMO (MU-MIMO for short) simultaneously distributes all of the available spatial streams of the LANCOM LX-6402 between several different Wave 2 clients. rather than one after the other as was formerly the case. The available bandwidth is used efficiently and delays in the wireless network are substantially reduced. With Wi-Fi 6. MU-MIMO operates not only for the downlink but for the uplink as well.

Professional IoT support via BLE and USB
With the LANCOM LX-6402. you can easily dive into the world of the Internet-of-Things (IoT). Support for Bluetooth Low Energy (5.1) and USB 3.0 opens up many possibilities for you to communicate with modern WLAN sensors in devices or objects and use innovative applications such as asset tracking or digital signage with Wireless ePaper. In this way. you can easily operate solutions for digital room signage. electronic shelf labels. and other ePaper applications via the optionally available LANCOM Wireless ePaper USB.

OFDMA – carpooling in the radio field
Orthogonal Frequency Division Multiple Access (OFDMA) divides the frequency range of a Wi-Fi channel into a number of frequency blocks per unit of time. This creates subcarriers. which can be as narrow as just 2 MHz. Small data packets. so typical of IoT devices. no longer block entire 20-. 40- or even 80-MHz channels all by themselves. On the other hand. the Wi-Fi 6 access point is able to bundle multiple subcarriers. This is bit like carpooling. which stops the traffic being blocked by cars with just one occupant: Instead. the streets are freed up with just a few cars carrying several occupants.

160 MHz channel width
The access point can handle channel bandwidths of 20. 40. and 80 MHz (with 4 streams) and 160 MHz (with 2 streams). The channel width of 160 MHz enables a data throughput of up to 2.400 Mbps on appropriate terminals with two antennas that support the reception of two streams at 160 MHz in the 5 GHz frequency band.

Longer battery life thanks to TWT
Previously. smartphones. tablets and notebooks had to be ready to receive all the time so as not to miss their data packets. This can quickly use up battery charge. Wi-Fi 6 delivers a new technology to counteract power consumption on the client side. Target Wake Time. TWT for short. reduces consumption by allowing the access point and the client to negotiate exactly when the receiver should wake up to receive data packets.

Band steering
Optimized load balancing in your Wi-Fi by actively redirecting clients to the less congested and higher performance 5-GHz frequency band.

Operates via the LANCOM Management Cloud
The LANCOM LX-6402 offers unsurpassed user-friendliness: Managed through the LANCOM Management Cloud. it integrates into a holistic. automated network orchestration system based on software-defined networking technology.

Modern web interface for stand-alone operation
Modern dashboards clearly display the current Wi-Fi status and enable the simple configuration of individual Wi-Fi networks (SSID) and the associated network keys. Other options include smart features such as the easy integration of new clients using QR codes.

Features
Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate (2.4 GHz): 1150 Mbit/s
Maximum data transfer rate (5 GHz): 2400 Mbit/s
Ethernet LAN data rates: 10.100.1000.2500 Mbit/s
Number of users: 511 user(s)
Channel bandwidth: 160 MHz
Feature: MIMO
MIMO type: Multi User MIMO
Spread spectrum method: OFDMA
Modulation: 256-QAM. 1024-QAM
Feature: Fast roaming
Feature: VLAN support
Number of VLAN IDs: 4096
Feature: Band steering
Feature: Maximal-Ratio Combining (MRC)
Feature: Quality of Service (QoS) support
Security
Security algorithms: AES-CCMP. AES-GCMP. EAP-FAST. EAP-GTC. EAP-PEAP. EAP-TLS. EAP-TTLS. TKIP. WEP. WPA2. WPA3
Management features
Feature: Firmware upgradeable
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
USB connector type: USB Type-A
Feature: DC-in jack
Power
Feature: Power over Ethernet (PoE)
AC input voltage: 12 V
Design
Placement: Table
Product colour: White
Housing material: Synthetics
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: LED indicators
Antenna
Antenna type: External
Antenna direction type: Omni-directional
Antennas quantity: 4
Weight & dimensions
Width: 205 mm
Depth: 205 mm
Height: 42 mm
Packaging data
Package width: 385 mm
Package depth: 288 mm
Package height: 94 mm
Package weight: 1.92 kg
Packaging content
Quantity per pack: 1 pc(s)
Feature: AC adapter included
Cables included: LAN (RJ-45)
Feature: Quick start guide
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Logistics data
Customs product code (TARIC): 85176200
Harmonized System (HS) code: 85176990
Country of origin: Malaysia
