Zyxel WIFI6 AX1800 Outdoor NWA55AXE
Product code: 11504722 // MPN: NWA55AXE-EU0102F // EAN: 4718937621996
Similar products
Durable. Weatherproof Outdoor WiFi 6 AP
Thinking of upgrading to the 11ax (WiFi 6) technology for your outdoor wireless network? Zyxel NWA55AXE is your answer!
Designed for harsh outdoor environments. the IP55-rated. weatherproof NWA55AXE is the best WiFi 6 outdoor access point to extend your wireless network outside.
Smart Mesh for Extended Coverage
Zyxel Smart Mesh Technology not only forms dynamic wireless links between APs for extended range. but can also bridge the wireless connectivity from one building to another. It is no doubt that NWA55AXE is an ideal choice for a simple expansion of your outdoor wireless network or forming an interconnected wireless network through outdoor inter-building links.
Simple Installation. Easy Configuration.
Perfect for small business owners or SOHO users. the NWA55AXE supports both local GUI management and Nebula Cloud networking management. The simple setup in Nebula APP or web allows you to quickly configure the AP with only a few clicks. making it super easy to set up guest and employee network on your own and start enjoying the ultra-fast WiFi 6 speeds in no time.
Manage it your way!
The NWA55AXE with NebulaFlex offers the flexible manageability for you to freely choose between the local GUI management or onboarding to our super easy Nebula cloud management interface that you never need to worry about forgetting the IP address or lost account and password whatsoever.
Features
Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1775 Mbit/s
Maximum data transfer rate (2.4 GHz): 575 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Ethernet LAN data rates: 10.100.1000 Mbit/s
Networking standards: IEEE 802.11a. IEEE 802.11ac. IEEE 802.11ax. IEEE 802.11b. IEEE 802.11g. IEEE 802.11n. IEEE 802.3at
Channel bandwidth: 80 MHz
Feature: MIMO
MIMO type: Multi User MIMO
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Fast roaming
Feature: VLAN support
Feature: Band steering
Transmitting power: 26 dBmW
Receiver sensitivity: -99 dBm
Security
Security algorithms: WPA. WPA-PSK. WPA2. WPA2-PSK. WPA3. WPA3-PSK
Feature: MAC address filtering
Feature: Auto Wireless Distribution System (WDS)
Management features
Feature: Web-based management
Feature: Firmware upgradeable
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Power
Feature: Power over Ethernet (PoE)
Power consumption (typical): 16 W
Design
Product colour: White
Antenna
Antenna type: External
Antennas quantity: 2
Antenna gain level (max): 5 dBi
Weight & dimensions
Width: 308 mm
Depth: 136.4 mm
Height: 49.6 mm
Weight: 580 g
Packaging data
Package width: 221 mm
Package depth: 188 mm
Package height: 59 mm
Package weight: 887 g
Packaging content
Quantity per pack: 1 pc(s)
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Master (outer) case width: 315 mm
Master (outer) case length: 483 mm
Master (outer) case height: 332 mm
Master (outer) case gross weight: 13 kg
Products per master (outer) case: 7 pc(s)
Thinking of upgrading to the 11ax (WiFi 6) technology for your outdoor wireless network? Zyxel NWA55AXE is your answer!
Designed for harsh outdoor environments. the IP55-rated. weatherproof NWA55AXE is the best WiFi 6 outdoor access point to extend your wireless network outside.
Smart Mesh for Extended Coverage
Zyxel Smart Mesh Technology not only forms dynamic wireless links between APs for extended range. but can also bridge the wireless connectivity from one building to another. It is no doubt that NWA55AXE is an ideal choice for a simple expansion of your outdoor wireless network or forming an interconnected wireless network through outdoor inter-building links.
Simple Installation. Easy Configuration.
Perfect for small business owners or SOHO users. the NWA55AXE supports both local GUI management and Nebula Cloud networking management. The simple setup in Nebula APP or web allows you to quickly configure the AP with only a few clicks. making it super easy to set up guest and employee network on your own and start enjoying the ultra-fast WiFi 6 speeds in no time.
Manage it your way!
The NWA55AXE with NebulaFlex offers the flexible manageability for you to freely choose between the local GUI management or onboarding to our super easy Nebula cloud management interface that you never need to worry about forgetting the IP address or lost account and password whatsoever.
Features
Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1775 Mbit/s
Maximum data transfer rate (2.4 GHz): 575 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Ethernet LAN data rates: 10.100.1000 Mbit/s
Networking standards: IEEE 802.11a. IEEE 802.11ac. IEEE 802.11ax. IEEE 802.11b. IEEE 802.11g. IEEE 802.11n. IEEE 802.3at
Channel bandwidth: 80 MHz
Feature: MIMO
MIMO type: Multi User MIMO
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Fast roaming
Feature: VLAN support
Feature: Band steering
Transmitting power: 26 dBmW
Receiver sensitivity: -99 dBm
Security
Security algorithms: WPA. WPA-PSK. WPA2. WPA2-PSK. WPA3. WPA3-PSK
Feature: MAC address filtering
Feature: Auto Wireless Distribution System (WDS)
Management features
Feature: Web-based management
Feature: Firmware upgradeable
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Power
Feature: Power over Ethernet (PoE)
Power consumption (typical): 16 W
Design
Product colour: White
Antenna
Antenna type: External
Antennas quantity: 2
Antenna gain level (max): 5 dBi
Weight & dimensions
Width: 308 mm
Depth: 136.4 mm
Height: 49.6 mm
Weight: 580 g
Packaging data
Package width: 221 mm
Package depth: 188 mm
Package height: 59 mm
Package weight: 887 g
Packaging content
Quantity per pack: 1 pc(s)
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%
Logistics data
Harmonized System (HS) code: 85176990
Country of origin: China
Master (outer) case width: 315 mm
Master (outer) case length: 483 mm
Master (outer) case height: 332 mm
Master (outer) case gross weight: 13 kg
Products per master (outer) case: 7 pc(s)
