DIGITAL SIGNAGE

The Avocor H Series redefines interactive displays for modern workspaces. emphasizing seamless collaboration and connectivity. With its ultra-thin bezel and sophisticated design. it integrates effortlessly into professional environments. enhancing aesthetic appeal and functional utility. This sleek design. devoid of visible buttons or inputs. maintains a sophisticated and uncluttered profile. perfectly complementing the aesthetic standards of today's workspaces. Across all models (65". 75". and 86"). the H Series boasts a high-resolution 4K display. bringing life to content with unparalleled clarity.

The Avocor H Series has a premium feel that will enhance any meeting room. and the technology needed to accommodate high collaboration in hybrid workspaces.

Ensure every in-person and remote interaction provides a natural and intuitive meeting experience with the Avocor H Series. the perfect solution for organizations that demand both a luxury aesthetic and a high performing functional workspace.

In the hybrid work era. the H Series excels in corporate settings with its sleek design and advanced touch technology. enhancing collaboration among remote and in-office teams. Its easy installation and FUSE-powered remote management streamline IT operations. while diverse connectivity options ensure seamless device integration. The addition of Montage and Rise Vision transforms idle screens into dynamic communication hubs. keeping all team members engaged and informed. thus embodying a versatile solution for modern corporate challenges.

Display
Display diagonal: 2.18 m (86")
Display brightness: 400 cd/m²
Display number of colours: 1.07 billion colours
Display resolution: 3840 x 2160 pixels
Feature: Anti-glare screen
HD type: 4K Ultra HD
Panel type: LCD
Feature: LED backlight
LED backlighting type: Direct-LED
Native aspect ratio: 16:9
Contrast ratio (typical): 5000:1
Response time: 6.5 ms
Maximum refresh rate: 60 Hz
Feature: Touchscreen
Touch technology: Multi-touch
Touchscreen type: Capacitive
Number of simultaneous touchpoints: 40
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Screen glass thickness: 2 mm
Feature: Pen & touch differentiation
Network
Feature: Wi-Fi
Antenna type: 1x1
Feature: Ethernet LAN
Feature: Wake-on-LAN ready
Ports & interfaces
Feature: HDCP
HDCP version: 2.3
USB connector type: USB Type-A. USB Type-B. USB Type-C
USB 2.0 Type-A hub ports quantity: 2
USB 2.0 Type-B Touch ports quantity: 3
HDMI ports quantity: 4
USB Type-C ports quantity: 1
Feature: USB Type-C DisplayPort Alternate Mode
HDMI version: 2.0
HDMI output ports quantity: 1
Feature: USB Power Delivery (USB PD)
USB Power Delivery up to: 100 W
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 2
Feature: Line-out
OPS slot: 1
Feature: S/PDIF out port
Audio output: 1
RS-232 ports: 1
Ergonomics
Product colour: Brushed steel
Feature: VESA mounting
Performance
Feature: Ambient light sensor
Feature: Proximity sensor
Power
Power consumption (max): 390 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 85%
Storage temperature (T-T): 20 - 85 °C
Weight & dimensions
Width: 1962 mm
Depth: 80 mm
Height: 1141 mm
Weight: 61 kg
Packaging data
Package width: 2110 mm
Package depth: 225 mm
Package height: 1270 mm
Package weight: 81 kg
Quantity per pack: 1 pc(s)
Packaging content
USB cable length: 3 m
Cables included: HDMI. USB Type-A to USB Type-B. USB Type-C to USB Type-C
Feature: Remote control included
Feature: Batteries included
Feature: Quick start guide
Feature: Stylus included
Stylus pen type: Passive
Number of stylus pens: 2
Other features
Warranty period: 3 year(s)
Country of origin: China
