MONITORS

Experience improved visual comfort. peak productivity and extensive connectivity with this hub monitor certified by TÜV for 4-star eye comfort.

Display
Display diagonal: 60.5 cm (23.8")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Native aspect ratio: 16:9
Display technology: LCD
Panel type: IPS
Backlight type: Edge LED
Display brightness (typical): 250 cd/m²
Response time: 8 ms
Feature: Anti-glare screen
Screen shape: Flat
Supported video modes: 480p. 576p. 720p. 1080i. 1080p
Contrast ratio (typical): 1000:1
Maximum refresh rate: 120 Hz
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Display number of colours: 16.7 million colours
Response time (fast): 5 ms
Pixel pitch: 0.2745 x 0.2745 mm
Pixel density: 92.53 ppi
Horizontal scan range: 31 - 135 kHz
Vertical scan range: 48 - 120 Hz
Viewable size. horizontal: 52.7 cm
Viewable size. vertical: 29.6 cm
Viewable size diagonal: 60.5 cm
Display diagonal (metric): 60.47 cm
Surface hardness: 3H
Colour gamut standard: DCI-P3
Colour gamut: 85%
sRGB coverage (typical): 100%
Performance
Feature: Flicker-free technology
Feature: Low Blue Light technology
Design
Market positioning: Business
Product colour: Black. Silver
Front bezel colour: Black
Feet colour: Silver
Ports & interfaces
Feature: Built-in USB hub
USB hub version: 3.2 Gen 2 (3.1 Gen 2)
USB upstream port type: USB Type-C
Number of USB Type-C upstream ports quantity: 2
USB Type-A downstream ports quantity: 4
USB Type-C downstream ports quantity: 1
Feature: USB Type-C DisplayPort Alternate Mode
Feature: USB Power Delivery (USB PD)
USB Power Delivery up to: 90 W
Feature: HDMI
HDMI ports quantity: 1
HDMI version: 1.4
DisplayPorts quantity: 2
DisplayPort version: 1.4
Feature: Headphone out
Feature: HDCP
HDCP version: 1.4
Feature: AC (power) in
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Height adjustment
Adjustable height (max): 15 cm
Feature: Pivot
Pivot angle: -90 - 90°
Feature: Swivelling
Swivel angle range: -45 - 45°
Feature: Tilt adjustment
Tilt angle range: -5 - 21°
Feature: On Screen Display (OSD)
Power
Energy efficiency class (SDR): D
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 15 kWh
Power consumption (typical): 14.5 W
Power consumption (standby): 0.5 W
Power consumption (max): 210 W
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Input current: 2.2 A
Power supply type: Internal
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 1585563
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 80%
Storage relative humidity (H-H): 5 - 90%
Operating altitude: 0 - 5000 m
Non-operating altitude: 5000 - 12192 m
Weight & dimensions
Width (with stand): 538.6 mm
Depth (with stand): 181.8 mm
Height (with stand): 496.5 mm
Weight (with stand): 5.55 kg
Width (without stand): 538.6 mm
Depth (without stand): 49.1 mm
Height (without stand): 311.2 mm
Weight (without stand): 3.98 kg
Bezel width (side): 5.8 mm
Bezel width (top): 5.8 mm
Bezel width (bottom): 8.95 mm
Packaging data
Package weight: 8.45 kg
Packaging content
Feature: Stand included
Cables included: AC. DisplayPort. USB Type-A to USB Type-C
Feature: Power adapter included
Feature: Quick start guide
DisplayPort cable length: 1.8 m
Sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR. TCO
Doesn't contain: PVC/BFR
Carbon footprint
Total carbon footprint (kg of CO2e): 535
Total carbon emissions. standard deviation (kg of CO2e): 122
Carbon emissions. manufacturing (kg of CO2e): 381.12
Carbon emissions. logistics (kg of CO2e): 40.69
Carbon emissions. energy usage (kg of CO2e): 108.8
Carbon emissions. end-of-life (kg of CO2e): 6.99
Total carbon emissions. w/o use phase (kg of CO2e): 426.2
PAIA version: 1.3.2. 2022
Other features
Heavy metals free: Hg (mercury)
Compliance certificates: RoHS
Ethernet LAN (RJ-45) ports: 1
