Lenkeng HDMI Extender over Ethernet 50m 4K POC IR Loop LKV465P
Product code: 17978720 // MPN: LKV465P
New entry
Similar products
- This is an HDMI point-to-point extender kit, it can realize zero-latency transmission
- The 4K@60Hz HDMI signal can be extended by 50m through CAT6/6A/7 network cable
- It supports HDMI loop out, IR passthrough, etc
- HDMI Length ≤5m
- Maximum transfer rate 18Gbps
- Maximum transmission bandwidth 600MHz
- EDID passthrough Yes
- Compatibility HDMI 2.0（Deep color, 4K, HDR, YUV4:4:4）
- HDCP 2.2, HDCP1.4
- Resolutions 480i@60Hz、480p@60Hz、576i@50Hz、576p@50Hz、 720p@50/60Hz、1080i@50/60Hz、1080p@50/60Hz、 3840x2160@24/25/30/50/60Hz、3440x1440、2560x1440、 2560x1080、2048x1080、1920x1440、1920x1080、 1280x960、1280x800、1280x768、1680x1050、 1360x768、1366x768、1600x900、1024x768、800x600
- Transmission distance 4K transmission distance 50m
- 1080p transmission distance 70m
- Audio formats LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
- IR interface 1x 3.5mm IR OUT Female
- 1x 3.5mm IR IN Female
- Receiving range ≤5m
- Infrared frequency 20KHz~60KHz
- Power Supply TX: DC5V/2A
- RX: PoC（Powered by TX）
- Power Consumption TX+RX＜5.5W
- Working temperature -20℃~60℃
- Storage temperature -30℃~70℃
- Humidity 0~90%RH（No condensation）
- Housing Metal
- Weight TX : 130g
- RX：130g
- Color Black
- Dimensions 75.0(L)*60.0(W)*21.0(H)mm
- Protection ESD protection
- 1a Contact discharge level 2 (±4KV)
- 1b Air discharge level 3 (±8KV)
- Implementation of the standard: IEC61000-4-2
- Lightning protection, Surge protection
